320
Setting ranges by color depth
8BIT
0 - 255
9BIT
0 - 511
10BIT
0 - 1023
11BIT
0 - 2047
12BIT
0 - 4095
13BIT
0 - 8191
14BIT
0 - 16383
15BIT
0 - 32767
(6)
User Color 1 R, G, B
When RGB 0%/100% has
been selected for Color
Select, set any color and
level to be indicated by
“0%.”
In the case of the Sub
Pixel item, the same level
as the RGB level is set.
The setting range differs
depending on the color
depth.
16BIT
0 - 65535
(7)
User Color 2 R, G, B
When RGB 0%/100% has been selected for Color Select, set any color and
level to be indicated by “100%.”
In the case of the Sub Pixel item, the same level as the RGB level is set.
The setting range is the same as for User Color 1.
To Next Page
