Chapter 6 PATTERN SETTINGS
359
<Table of name setting items>
The display contents of Name are set here.
0
Program Name
The program names are displayed.
1
Pattern Name
The pattern names are displayed.
2 Program & Pattern
Name
The program names and pattern names are
displayed at the same time.
(1)
Format (0-3)
3
Program Name, Freq
The program names and video timing signal
frequencies are displayed at the same time.
The display position of the name is set here.
0
Center
The name is displayed at the screen center.
1
Top-Left
The name is displayed at the top left of the
screen.
2
Bottom-Left
The name is displayed at the bottom left of the
screen.
3
Top-Right
The name is displayed at the top right of the
screen.
4
Bottom-Right
The name is displayed at the bottom right of the
screen.
5
Top-Center
The name is displayed at the upper center of the
screen.
(2)
Position
6
Bottom Center
The name is displayed at the lower center of the
screen.
The font size is set here.
0
5 × 7
5 × 7 is set as the font size.
1
7 × 9
7 × 9 is set as the font size.
(3)
Font
2
16 × 16
16 × 16 is set as the font size.
The display position can be adjusted in such a way that the display is not
hidden to simulate an overscanning monitor.
H =
Set the horizontal overscanning ratio.
(4)
Overscan [%]
V =
Set the vertical overscanning ratio.
(5)
Pattern Name
The pattern names are edited here.
For details on the editing procedure, refer to “2.3 Setting the names.”
