<Frame Sequential 3D patterns>
Patterns are drawn as shown in the figure below when Frame Sequential has been selected as the Output Mode
setting among the 3D pattern (OPT No.101) settings in section 6.9.6.
This pattern is displayed at the left and right alternatively, and the Frame Sequential operation is performed by
setting H=1 and V=2 as the values for the “Repeat” parameter among the simple animation settings in section
6.15.2.
The Interval1 parameter also takes effect at this time.
V-DISP
V-DISP
H-DISP
Left side pattern
Right side pattern
