<Example of simple animation frame trigger settings>
●EXP.1 F1 F2 F3 F4 F5 F6 F7 F8 F9 F10
V-Sync
①②③④ ⑤
OUT0 (MLB)
OUT1
OUT2
OUT3 (MSB)
Number Of Fram
e
:5
Frame No. Data
①1: 1 1H
②2: 2 2H
③3: 3 4H
④4: 4 8H
⑤5: 8 fH
●EXP.2 F1 F2 F3 F4 F5 F6 F7 F8 F9 F10
V-Sync
①②③ ④
OUT0 (MLB)
OUT1
OUT2
OUT3 (MSB)
Number Of Fram
e
:4
Frame No. Data
①1: 1 9H
②2: 2 6H
③3: 3 cH
④4: 5 8H
