Chapter 11 SPECIFICATIONS
517
65 128-Gray H
66 RGBW Linear Ramp H
67 Linear Ramp & RGBW V 68 Linear Ramp & RGBW H
69 Multi-Color Ramp HV
70 Linear/256 Ramp H
71 Motion Blur Line
72 Spectrum
73 74 Ramp Limited-H
75 Ramp Limited-V
76
9 Marker
77 SMPTE Color CVBS *2
78 SMPTE Color COMP *3
101 3D Pattern *1
*1: This pattern requires the license. To purchase it, contact ASTRODESIGN sales.
*2: This is a minus level-compatible pattern used exclusively for analog CVBS outputs
. It cannot be displayed at the
correct level from other outputs.
*3: This is a minus level-compatible pattern used exclusively for analog component outputs. It cannot be displayed at the
correct level from other outputs.
