Atlas Copco PowerMACS 4000

System Architecture
9836 3521 01 25
Spindle
A Spindle performs the actual tightening task. One Spindle can be used to tighten several Bolts and it
normally comprises of:
 Motor
 Intelligent CPU with complete measuring system
 One or more torque sensors
 One or more angle sensors
ToolsTalk
ToolsTalk PowerMACS is a Windows application used to set up a PowerMACS 4000 system. It is not
needed for automatic running, but it can optionally be used to monitor the system and to collect and
display various data.
ToolsTalk PowerMACS can be used for multiple systems, if they are hooked up on the same computer
network, but only one system at a time can be accessed.
