Peripheral Devices
9836 3521 01 613
8.17.5.2 Spindle, Parameters
Syntax: Spindle[<spindle no>].<parameter>
<spindle no> = 1..Max spindle no
<parameter> = See table below (and Spindle Set Up for a description)
<parameter>
Data type
Description
NoCyclMaint
Long integer
Service interval in no. of cycles (>= 0)
Direction
Short integer
Direction in which the spindle should rotate. Allowed
values are:
0. Forward (clockwise)
1. Backward (counter clockwise)
ZeroSpeed
Float
The maximum speed that counts as zero speed
ADiffEnabled
Boolean
If angle channel difference test should be enabled
ADiffUseSpindle
Boolean
If spindle‟s limits should be used
ADiffMaxDiff
Float
Maximum allowed difference
ADiffSamples
Short integer
Maximum number of samples tolerated above
ADiffMaxDiff
TDiffEnabled
Boolean
If torque channel difference test should be enabled
TDiffUseSpindle
Boolean
If spindle‟s limits should be used
TDiffChannels
Short integer
Channels to compare
1 : Current compared to Torque Channel 1
2 : Current compared to Torque Channel 2 *(
3 : Torque Channel 1 compared to Torque Channel 2 (*
*) Requires two torque channels
TDiffMaxDiff
Float
Maximum allowed difference
TDiffSamples
Short integer
Maximum number of samples tolerated above
TDiffMaxDiff
ContFailedFzo
Boolean
True if spindle should continue to run after failed flying
zero offset check.
SzoMax1
Float
Max allowed static zero offset for transducer 1.
SzoMax2
Float
Max allowed static zero offset for transducer 2.
DzoMax1
Float
Max allowed dynamic zero offset for Torque 1.
DzoMax2
Float
Max allowed dynamic zero offset for Torque 2.
FzoMax1
Float
Max allowed flying zero offset for Torque 1.
FzoMax2
Float
Max allowed flying zero offset for Torque 2.
ExtEnabled
Boolean
True when external equipment enabled.
