8.17.5.5 Program, Trace data
Syntax: Program[<pgm name>].Trace.<parameter>
<pgm name> = The name of the program
<parameter> = See table below
description)
<parameter>
Data type
Description
TraceStart
Short integer
The main condition for when to start recording a Trace.
Takes the following values:
 1: At cycle start
 3: When the step with number <TraceStartStep> is
started.
TraceStartStep
Short integer
The number of the step where trace will start
TraceStartQty
Short integer
Specifies an addition condition for when to start recording
a trace. Takes one of the following values:
 0: None
 1: When the measured angle reaches the value
<TraceStartMin>
 2: When the measured torque reaches the value
<TraceStartMin>
3: When the measured current reaches the value
<TraceStartMin>
TraceStartMin
Float
The minimum value to reach before trace starts. Valid
only if <TraceStartQty> has the value 1, 2 or 3.
Inc2ndTorque
Boolean
If true both torque channels will be recorded to trace.
Inc2ndAngle
Boolean
If true both angle channels will be recorded to trace.
Example: Program[Pgm01].General.StopMonAtNokStep
