Tightening
9836 3521 01 321
Angle
Torque
Time
Step start
Angle
Torque
Time
Zone start
Start condition:
Torque
Step start (AS1)
Shut off previous (AS2)
Peak angle previous
(AS3)
Start condition:
Torque
Zone start
Stop condition:
Shut off
Shut off previous
Peak Angle
Final Angle
Torque
Stop condition:
Zone end
Torque
Zone ended (if stop
condition is Zone
End)
6.5.4.1 Result values from checks
For each check it is possible to select the cycle data variable it shall use to store the result. Each check
type has its own specialized variables that can only be used for that check type (e.g. Peak T, Peak T1,
Peak T2 and Peak T3 for a peak torque check). There are also general variables available that can be
used for all check types.
The specialized variables can only be used in the correct check type with the correct channel selection for
torque or angle. For example Peak T can only be used in a peak torque check with the torque channel set
to Auto. A2 can only be used by an angle check with the angle channel set to Angle 2, etc.
Two sets of general variables are available, one on step level and one on bolt level, with 80 variables in
each set. The variables on step level are named Step var. 01, Step var. 02, etc, and the variables on bolt
