Peripheral Devices

452 9836 3521 01

8.11.2.1 Supported message types

Following message types are supported:

 0002: Test Results to PFCS from PFD

 9999: Keep alive message from PFD

PFCS can also send a 0003 message, unsolicited vehicle data, to PFD. PFD will accept the message and

return an ACK message but will currently not perform any actions.

Please see chapter Cycle Data Storage for more information about saving cycle data.

8.11.2.2 PFD Result Record Formats

The tightening results are reported to PFCS according to the specification, with following additional

information.

Field

Implementation

VIN

Last 6 characters of the ID string

Track Seq No

Always 000000

Spindle Number

Bolt number

Bolt Count

Bolt number

Torque High Limit

Torque high limit from the Monitor function

Torque Low Limit

Torque low limit from the Monitor function

Torque Reading

Torque value the Monitor function

Angle High Limit

Angle high limit from the Monitor function

Angle Low Limit

Angle low limit from the Monitor function

Angle Reading

Angle value the Monitor function
