Atlas Copco PowerMACS 4000 User Manual

Peripheral Devices
9836 3521 01 455
8.11.3.2 TC Result Record Formats
The tightening results are reported to FSH according to the specification, with following additional
information.
Field
Implementation
Network Id
IP address of TC.
Station Number
Configurable via ToolsTalk PowerMACS.
Cycle Number
Data Number.
Number of Spindles
Reports number of bolts in the cycle data.
Parameter Set
Mode number
Supplier Code
"ACS".
Vehicle ID code. (PVI No)
ID device string converted to a number.
Spindle
Ordinal bolt number within the station.
Torque
Bolt Torque from the Monitor function.
Torque Low Limit
Bolt Torque, Min limit, from the Monitor function.
Torque High Limit
Bolt Torque, Max limit, from the Monitor function.
Angle
Bolt Angle from the Monitor function.
Angle Low Limit
Bolt Angle, Min limit, from the Monitor function.
Angle High Limit
Bolt Angle, Max limit, from the Monitor function.
Status Bits
Completion, Torque Status, Torque Spec, Angle Status, and Angle Spec
are set in accordance to the corresponding bits in the Bolt level result
variables "Compact Errors".
The Time Status and Time Spec bits are set according to the status of the
bits TIR, TIL, TIH in the Bolt level result variables "Errors". The following
rules are used::
 If neither TIR, TIL nor TIH are set then Time Status and Time
Spec are set to 0.
 If at least one of TIR, TIL or TIH is set then Time Status is set to 1.
If TIL is set then Time Spec is set to 0 (regardless if TIR and/or TIH
are set as well). If only TIR and/or TIH are set then Time Spec is set to
1.
Tool Serial Number
The value of the Spindle Set Up/General parameter "Spindle Serial
Number" for the spindle that was used to tighten the bolt in
question.
