Atlas Copco PowerMACS 4000 User Manual

Tightening
9836 3521 01 385
6.7.3 Bolt level result variables
Bolt level data is divided in two parts, Common data and Monitoring data where the latter consists of all
variables that are produced by the Bolt Monitoring functions.
Common data
The Common data consists of the following variables:
Variable name
Description
Bolt
The name of the bolt. Set System for how to set or change the name of a bolt. Max. 20
ASCII characters.
Bolt No
The number of the bolt as configured.
Spindle No
The number of the TC used to tighten the bolt as configured.
Program
The name of the program used to tighten the bolt. Max. 20 ASCII characters.
OP mode
Operational mode of the bolt. Takes one of the following values:
 0: Connect normally. The bolt was executed during the cycle.
 1: Disconnected with OK status. The bolt was not executed during the cycle.
 2: Disconnected with NOK status. The bolt was not executed during the cycle.
Status
Overall status for the bolt including monitoring. See chapter: Statuses for possible values.
Total
Total number of cycles that this bolt has run during the current shift. See Shift Reports and
Shift Set Up for a description of shifts.
Total OK
Total number of OK and OKR cycles that this bolt has run during the current shift. See
Shift Reports and Shift Set Up for a description of shifts..
Total NOK
Total number of NOK and TERMNOK cycles that this bolt has run during the current shift.
See Shift Reports and Shift Set Up for a description of shifts.
Total Type
The total number of cycles that all bolts, which is of the same type as this bolt, have run
during the current shift. The bolt type is a property that can be accessed from the System
Map. See Shift Reports and Shift Set Up for a description of shifts.
Total Type OK
The total number of OK and OKR cycles that all bolts, which is of the same type as this
bolt, have run during the current shift. The bolt type is defined using the System Map. See
Shift Reports and Shift Set Up for a description of shifts.
Total Type NOK
The total number of NOK and TERMNOK cycles that all bolts, which is of the same type
as this bolt, have run during the current shift. The bolt type is defined using System Map.
See Shift Reports and Shift Set Up for a description of shifts.
Errors
Lists all errors that have occurred during the cycle and is not repaired. See Errors for
possible values.
RM Errors
Lists all errors that have occurred during the cycle including all that have been repaired.
See Errors for possible values.
Warnings
Lists all warnings that have occurred during the cycle. See Warnings for possible values.
