Atlas Copco PowerMACS 4000 User Manual

Tightening
384 9836 3521 01
Variable name
Description
Free No 2
The value of the PLC output FREENUM2 when the cycle was started (see Station
variables).
Free Str 2
The value of the PLC output FREESTRING2 when the cycle was started (see Station
variables).
Free Str 3
The value of the PLC output FREESTRING3 when the cycle was started (see Station
variables).
Data No Station
A tightening unique sequence number. This number is incremented by one for each cycle
produced by the station.
Data No System
A tightening unique sequence number. This number is incremented by one for each cycle
produced by the system.
Station QO
A variable specific for the PLUS protocol. The variable will only have a valid value if a
PLUS device is defined. The value is taken from the QO/SA Table in the PLUS device.
Station SA
A variable specific for the PLUS protocol. The variable will only have a valid value if a
PLUS device is defined. The value is taken from the QO/SA Table in the PLUS device.
Station AB
A variable specific for the PLUS protocol. The variable will only have a valid value if a
PLUS device is defined. The value is taken from Station AB in the PLUS device.
ID Res 1
Multiple identifiers result variable 1. Max. 40 ASCII characters.
ID Res 2
Multiple identifiers result variable 2. Max. 40 ASCII characters.
ID Res 3
Multiple identifiers result variable 3. Max. 40 ASCII characters.
ID Res 4
Multiple identifiers result variable 4. Max. 40 ASCII characters.
No Bolts
Number of bolts in the Cycle Data
ID Res 5
Multiple identifiers result variable 4. Max. 40 ASCII characters.
ID Res 6
Multiple identifiers result variable 4. Max. 40 ASCII characters.
Audi PRT Tag
A variable specific for the Audi XML protocol. The variable will only have a valid value if a
Audi XML device is defined.
Audi PI1 Tag
A variable specific for the Audi XML protocol. The variable will only have a valid value if a
Audi XML device is defined.
Audi PI2 Tag
A variable specific for the Audi XML protocol. The variable will only have a valid value if a
Audi XML device is defined.
Audi STC Tag
A variable specific for the Audi XML protocol. The variable will only have a valid value if a
Audi XML device is defined.
