Atlas Copco PowerMACS 4000

Basic Functions
9836 3521 01 85
3.6.8 View I/O signals
When ToolsTalk PowerMACS is connected you can display the current status of all digital inputs and
output connected to a particular TC. Use menu choice View-IO to open the IO Map form. (You can also
open it from the Hardware on the System Map form. Select the IO device for a TC and press
Advanced....)
