Atlas Copco PowerMACS 4000

Tightening
9836 3521 01 281
Diagram 2:
Angle
Previous
step
AStop
A
Step x
Step x-1
-OS
A2
Astop Shut-off point A Target Angle
A2 A - OS actual angle movement in this step
OS Overshoot in previous step
Trace: Angle A is shown as a horizontal line from step start to step stop in trace when Angle vs.
Time is selected. Control parameters must be enabled in the trace form (see View of
trace curves).
