Atlas Copco PowerMACS 4000

Tightening
286 9836 3521 01
Diagram:
Angle
Torque
T Torque Peak T Peak Torque
Mask1 Time 1
Mask2 Time 2
Step
Mask1
(time)
Mask2
(time)
Peak T
T
Release Angle
Trace: Torque T is shown as a horizontal line from step start to step stop in trace when Torque vs.
Time is selected. Control parameters must be enabled in the trace form (see View of
trace curves).
