Atlas Copco PowerMACS 4000

Tightening
288 9836 3521 01
Diagram:
Angle
Torque
T Torque Peak T
Mask1 Time 1 Peak T * 0.3 Shut off point
Mask2 Time 2
Step
Mask1
(time)
Mask2
(time)
Peak T
Release Angle
Peak T * 0.3
T
Trace: Torque T is shown as a horizontal line from step start to step stop in trace when Torque vs.
Time is selected. Control parameters must be enabled in the trace form (see View of
trace curves).
