Atlas Copco PowerMACS 4000

Tightening
9836 3521 01 387
Variable name
Description
Customer Error
Code
A four (4) character string with a customer configurable error code. The mapping of
PowerMACS errors to customer error codes are done in the Options window, click on
button "Set Customer error codes…"
Mon A Chan
Angle channel used for monitoring.
Mon T Chan
Torque channel used for monitoring.
Con A Chan
Angle channel used for control.
Con T Chan
Torque channel used for control.
Mon Buf 1 A
Angle channel used for first monitoring buffer.
Mon Buf 1 T
Torque channel used for first monitoring buffer.
Mon Buf 2 A
Angle channel used for second monitoring buffer.
Mon Buf 2 T
Torque channel used for second monitoring buffer.
No. Steps
Number of steps stored in the Cycle Data.
Spindle Art. No
Spindle article number
Sp. total cycles
Spindle Total cycles produced by the spindle
Sp. cycles since
serv.
Spindle Cycles since last service
Sp. cycl. to serv.
Spindle Cycles to next service
Spindle type
Spindle type
Data missing
Is 1 if data for a specific bolt is missing and 0 if not.
Bolt Id
Bolt ID
Program version
A unique program version string. Can be used to check if two programs are equal or not.
Audi FAP Tag
A variable specific for the Audi XML protocol. The variable will only have a valid value if a
Audi XML device is defined.
Audi FNR Tag
A variable specific for the Audi XML protocol. The variable will only have a valid value if a
Audi XML device is defined.
Audi COM Tag
A variable specific for the Audi XML protocol. The variable will only have a valid value if a
Audi XML device is defined.
Audi CNR Tag
A variable specific for the Audi XML protocol. The variable will only have a valid value if a
Audi XML device is defined.
Audi WID Tag
A variable specific for the Audi XML protocol. The variable will only have a valid value if a
Audi XML device is defined.
Audi SIO Tag
A variable specific for the Audi XML protocol. The variable will only have a valid value if a
Audi XML device is defined.
Audi GNR Tag
A variable specific for the Audi XML protocol. The variable will only have a valid value if a
Audi XML device is defined.
Audi GAP Tag
A variable specific for the Audi XML protocol. The variable will only have a valid value if a
Audi XML device is defined.
