Peripheral Devices
458 9836 3521 01
Send cycle data automatically -Controls the sending of cycle data. If checked the result from a
tightening will be sent to PLUS immediately after the cycle has finished.
If the connection to the PLUS server is broken when the cycle is finished the data will be sent when the
connection is established again.
If unchecked the sending of data is controlled by the PLC variable PLUS_DOKUENABLE instead.
Conversion table -Converts the received TMUs to a mode number. Has the same functionality as the
conversion tables used for the Stations Work piece identifier and Multiple identifiers functions.
QO/SA table -The value to use as QO, “Qualitätsaussage Orts Nr”, and SA, “Soll anzahl
Einzelergebnisse” when sending cycle data to PLUS is dependent on the mode used for the tightening.
The QO and SA to use are specified in this table with one row for each mode. If no values are specified for
a mode, cycle data produced when running this mode will not be sent to the PLUS server.
The values specified will also be included in the cycle data as the result variables Station QO and Station
SA.
The value specified as QO will also be used as AO, “Anlagen Orts Nr”, for all bolts in the cycle data.
Strings entered in the columns US if OK, US if OKR and US if NOK for a specific mode are used in the
cycle data US field. US is part of the bolt data. The bolt status is used to select the correct field in the
table.
If no string is entered the value in result variable Id Res 4 is used instead.
Test PLUS -When this button is pressed the connection to the PLUS server is tested. The result of the
test will be indicated as OK or NOK. The test button is only available if the advanced form is opened
connected to the target system.
