Peripheral Devices
9836 3521 01 469
Result data:
Bolt level data
This table describes the data sent to PLUS if Bolt level data is reported
The value reported from “Final Torque at cycle end”
monitoring.
The torque is multiplied by 100 and is sent as an integer (2
decimals rounded).
The value reported from “Angle from threshold to Cycle
End” monitoring.
Are always sent as an integer with unit degrees. The value
is rounded to nearest integer.
The step number will always be 0 to indicate that it is bolt
data
Step level data
This table describes the data sent to PLUS if step level data is reported. All the step data will come from
the same step.
The value reported from a “Check shut off torque” check.
The torque is multiplied by 100 and is sent as an integer (2
decimals rounded).
The value reported by a “Check angle” check.
Are always sent as an integer with unit degrees. The value
is rounded to nearest integer.
The number of the step that produced the other data.
The highest current reached during the step. Reported by a
“Check peak torque” check running on channel T3.
The current is converted to torque, which is then multiplied
by 100 and sent as an integer (2 decimals rounded).
