Peripheral Devices
9836 3521 01 471
Result data:
The following data is possible to report to DC PLUS. By default only the Torque, Angle, Redundancy
Torque and the Step number is included. The other data can be selected in the reporter if wanted.
Bolt level data
This table describes the data sent to PLUS if the Bolt level data is reported
Only sent if limits for Bolt T is selected in the reporter
Only sent if limits for Bolt T is selected in the reporter
Are always sent as an integer with unit degrees. The value
is rounded to nearest integer.
Only sent if limits for Bolt A is selected in the reporter
Only sent if limits for Bolt T is selected in the reporter
This value is not possible to send.
The step number will always be 0 to indicate that it is bolt
data
Step level data
This table describes the data sent to PLUS if step level data is reported. All the step data will come from
the same step.
The value reported from a “Check shut off torque” check.
The torque is multiplied by 100 and is sent as an integer (2
decimals rounded).
Only sent if limits for SO T is selected in the reporter
Only sent if limits for SO T is selected in the reporter
The current is converted to torque.
Are always sent as an integer with unit degrees. The value
is rounded to nearest integer.
Only sent if limits for A is selected in the reporter
