Peripheral Devices
9836 3521 01 513
Three LED‟s on the AnyBus module indicate the status of the Profibus. These LED:s can also be
displayed from the System Map form, see Indication of the fieldbus node’s for how to do this.
The function of the respective LED is as follows:
Steady off – Not online / No Power.
Steady Green – On-line, data exchange.
Flashing Green – On-line, clear.
Flashing Red (1 flash)- Error in "Set Prm service".
Flashing Red (2 flashes)- Error in "Chk_Cfg service".
Steady off – No power or not initialized.
Steady Green – Initialized.
Flasing Green – Initialized, diagnostic event(s) present.
Steady Red - Exception Error.
