Peripheral Devices
9836 3521 01 515
The AnyBus-CC IN and OUT areas can be configured to a maximum size according to the following table:
Max fast bytes In/Out
(Total)
Max Acyclic bytes In/Out
(Total)
Mapped as an 8 bit byte
array.
Mapped as a 16 bit word
array.
Mapped as a 32 bit double
word array.
Mapped as a 64 bit quad
word array.
Note: When the cyclic IO data is configured on the ProfiNet IO master side it must be done in the following
order:
1. All data sent from the master to PowerMACS
2. All data sent from PowerMACS to the master
Acyclic data Inputs to PowerMACS are sent with “Write record” commands and acyclic data Outputs from
PowerMACS are sent with “Read record” commands and are mapped to parameter data as follows:
