Basic Functions
62 9836 3521 01
When connected to a system the Station and Bolt nodes will display certain colors depending on the last
status.
NOK - Idle after NOK cycle
NOKRM - Idle NOK only due to reject management after a cycle. For bolts only
Bolt is disconnected. This color is only used if the checkbox Display disconnected bolts with blue
color in the Options form is checked.
If not checked then disconnected OK bolts will be green and disconnected NOK bolts will be red.
For bolts only
Below the actual tree are the particular Details for the currently selected item listed. Use the Details
window to edit data for an item. By default the Details window is placed below the actual system tree but it
can be placed anywhere on the screen by drag & drop.
