SmartROC D65 Tier 4 Final 8 Track frames
152
Limberoller T45, C50, D55, T50SF, C65SF
Limberoller T50LF, D60, D65, C65LF
Wear New
limber-
oller
25% 50% 75% 100%
A mm 100.0 98,5 96,7 94,6 92,0
B mm 7,5 8.2 9.1 10,2 11.5
8.3.4 Check for wear on the front wheel
Check the wear by measuring the distance between the top and bottom of the front wheel.
Front wheel
