SmartROC D65 Tier 4 Final 13 Oil and fuel
188
!
NOTE: Always use a funnel with strainer when refilling.
NOTE: If the lubricating system is fully drained of oil then the system must be bled.
See the maintenance instructions for the drill system.
13.9 For engine oil and fuel, see chapter "Diesel engine".
13.10 Draining the fluids
1 Engine radiator
2 Hydraulic oil cooler
3 Compressor cooler
4 Compressor element
5 Engine oil
6 Compressor tank
