SmartROC D65 Tier 4 Final 3 Transport instructions
34
Left control panel
n Make sure that none of the hoses, controls or any other components can fasten or
sustain damage when the hoisting slings are tensioned and under load.
n Place the hoisting slings under both crawler tracks at points A and B as shown in the il-
lustration Hoisting.
3.2 Transport
WARNING
Serious injury
Risk of dumping
u May cause serious personal injury and damage to property
u Lock the track oscillation cylinders before the drill rig is raised
u Transportation equipment must be adapted for the dimensions and weight of the drill rig
Normal tramming position
