SmartROC D65 Tier 4 Final 13 Oil and fuel
190
Ambient temperature. 25-50
(°C) St.
Viscosity grade VG (ISO
3448)
Viscosity index VI
+ 25 to +50 ISO VG 68 Min. 150
0 to +25 ISO VG 46 Min. 150
-30 to 0 ISO VG 32 Min. 150
Table17: Ambient temperature °C
!
NOTE: When operating in extremely low temperatures, installation of an extra heater is
recommended.
13.11.3 Lubricating oil tank (ECL) (ECG) (HECL)
Atlas Copco recommends the use of Atlas Copco COP OIL which has been specially de-
veloped for our hydraulic rock drills and DTH hammers.
COP OIL is an environmentally friendly, degradable oil which can be used in ambient tem-
peratures between -25 °C and +50 °C.
If COP OIL is not available then the oil should have the following properties:
n Use an oil with good lubricating properties intended for compressed air tools.
n Depending on ambient temperature, the oil should have the following viscosity grades
if the viscosity index (VI) is about 100:
Ambient temperature °C Viscosity grade (ISO 3448)
-30 till +-0 VG 32 - 68
-10 till +20 VG 68 - 100
+10 till +50 VG 100 - 150
n The oil must have additives that prevent foam formation.
ASTM D 2783 Min. 250 kg
ASTM D 4172 (40 kg) Max. 0.5 mm
n The oil must have good adhesion capacity.
n The oil must have additives that prevent foam formation.
13.11.4 Grease nipples and CLS
Working temperature °C
Universal grease NLGI 2
Lithium/molybdenum additives
Max. 100 °C
Synthetic sodium or calcium grease Max. 140 °C
Table18: Grease nipples and CLS
13.11.5 Rotation unit
Grease: lithium complex, mineral oil based EP grease. NLGI 2, Viscosity 300-600 cSt at 40
°C. Mechanically stable. Intended for use in vibration applications (Shell: Limona LX2).
