SmartROC D65 Tier 4 Final 13 Oil and fuel
186
2.
Switch off the rig and allow the oil level to settle for at least 5 minutes.
3.
Check the compressor oil level. The indicator on the gauge (1) must be in the green
zone.
4.
Fill with oil at (2), if required.
!
NOTE: Never fill with too much oil. Overfilling results in high oil consumption.
13.6 Oil sampling
An oil sample gives a good indication of how well the hydraulic system has been main-
tained.
13.7 Hydraulic oil
CAUTION
Risk of injury
Protect your eyes from hydraulic oil
!
NOTE: Do not fill up with too much hydraulic oil as it might then clog the ventilation fil-
ter.
The hydraulic oil level can be read in the sight glass on the front of the hydraulic oil reser-
voir. The lower sight glass (2) should be full and the upper sight glass (1) should be half
full.
n Check the hydraulic oil level (1 and 2)
n Fill with the hand pump (3) if necessary (see the chapter "Recommended oils and lub-
ricants")
