SmartROC D65 Tier 4 Final 4 Hardware RCS
44
Contact Function
X25 Power supply module
Table7: Functions of connections
4.3.2 Pin configurations
Contact Type Pin 1 Pin 2 Pin 3 Pin 4 Pin 5
X1, X19 Five-pin
M12, male
contact
Screen
(connected
to ground)
CAN +24V CAN GND CAN Hi CAN Lo
X2, X3, X4,
X20, X21, X22
Five-pin
M12, female
contact
+24V supply
voltage
sensor
0 - 5V input
signal
GND 0 - 20mA in-
put A
+5V supply
voltage
sensor
X5, X23 Five-pin
M12, female
contact
+12V supply
voltage
sensor
Input or out-
put B
GND Input or out-
put A
GND
X7, X8, X9,
X10, X14,
X15, X16, X24
Five-pin
M12, female
contact
+24V supply
voltage
Output B GND Output A GND
There are two outputs per contact, but only one output can be activated at a time.
Output current is between 50mA and 2.0A.
The amplitude is adjustable from 0 to 500mA in steps of 50mA.
X11, X12,
X17, X18
Five-pin
M12, female
contact
+24V supply
voltage
Input or out-
put B
GND Input or out-
put A
GND
X13 Five-pin
M12, male
contact
Bit 2 Bit 1 GND Bit 0 Bit 3
Each address bit is connected to GND (ground). The address plug can be connected
to four different addresses.
Bit 3 is used for baud rate. Unconnected = 125 kbit, connected = 250 kbit
X25 Five-pin
7/8", male
contact
+24V supply
voltage
+24V supply
voltage
GND GND +24V logic
voltage for
CPU and
communica-
tion
The current output for the contact is up to 18A.
4.3.3 LED functions
Module status (X25)
n When the system starts the LED flashes twice per second.
n When CAN communication is in progress the LED will flash once per second.
