SmartROC D65 Tier 4 Final 14 Options
193
14 Options
14.1 GPS
14.1.1 General
The GPS system consists of two antennas and one receiver. The antennas are fitted at a
distance of 0.5 metres apart. There must not be any permanent fixture between the anten-
nas and the horizon, apart from the drill rig's feeder.
14.1.2 General data
Voltage 24V DC
Current usage 0,2 A
Operating temperature +70°C - -30°C
Enclosure class IP65
Precision <0.3° rms
Start-up time <60 s
CAN test report form CAN Open
GPS compass
A Voltage cable
