n Engine Status
n Service Interval
n Configure
5.5.2 System - Modules
Four different views can be selected:
1.
Status View
2.
System Layout
3.
Rig Layout
4.
Feeder Layout
Status View
The status of all the modules can be checked in this menu:
n D500:1 Left lever module
n D500:2 Right lever module
n D501 Operator's display
n D569 Aim
n D100 Application module
n D510 I/O module
n D511 I/O module
n D512 I/O module
n D530 CAN bridge
n D101 I/O module
n D170 Boom articulation sensor
n D171 Feed Inclinometer Sensor
