SmartROC D65 Tier 4 Final 5 RCS drilling system
57
5.4 Direct selection menus
5.4.1 Direct selection menu F1.
Direct selection menu F1.
Symbol description for direct selection menu F1
!
NOTE: GPS is covered separately in the chapter entitled Options
The following is an explanation of the symbols shown in direct selection menu F1.
Symbol Name Explanation
Tank pressure Shows the current tank pressure
(bar).
Lubrication oil pressure Shows the current lubricating oil
pressure (bar).
Water amount Shows the percentage loading
of the watermist pump.
