Contact Type Pin 1 Pin 2 Pin 3 Pin 4 Pin 5
Each address ID is connected to GND (ground). The address plug can be connected
to four different addresses.
X6 Five-pin
M12, male
contact
RXD 1 GND TXD 1 RXD 0 TXD 0
4.5.3 Pin configurations X8 - X9
Pin X8 X9 Pin X8 X9
1 GND LED FEED 20 Ain 10 LED OUT 19
2 Ain 1 LED OUT 1 21 GND LED OUT 20
3 POT FEED LED OUT 4 22 Din 1 LED OUT 21
4 Ain 2 LED OUT 3 23 Din 2 LED OUT 22
5 GND LED OUT 4 24 Din 3 LED OUT 23
6 Ain 3 LED OUT 5 25 GND LED OUT 24
7 POT FEED LED OUT 4 26 Din 4 LED OUT 25
8 Ain 4 LED OUT 3 27 Din 5 LED FEED
8 GND LED OUT 4 28 Din 6 Kbd IN 1
10 Ain 5 LED OUT 9 29 GND Kbd IN 2
11 POT FEED LED OUT 4 30 Din 7 Kbd IN 3
12 Ain 6 LED OUT 3 31 Din 8 Kbd IN 4
13 GND LED OUT 4 32 Din 9 Kbd IN 5
14 Ain 7 LED OUT 13 33 GND Kbd OUT 1
15 POT FEED LED OUT 4 34 Din 10 Kbd OUT 2
16 Ain 8 LED OUT 3 35 Din 11 Kbd OUT 3
17 GND LED OUT 4 36 Din 12 Kbd OUT 4
18 Ain 9 LED OUT 17 37 GND Kbd OUT 5
19 POT FEED LED OUT 4
4.5.4 LED functions
Status View
n When the system starts the LED flashes twice per second.
n When CAN communication is in progress the LED will flash once per second.
n When there is no CAN communication or if the I/O module is starting up the LED will
flash five times per second.
