SmartROC D65 Tier 4 Final 14 Options
206
There are also a number of lubrication points.
A general inspection is recommended every week or every 50 engine hours.
Before any component is unscrewed the system should be depressurised. Failure to do so
would cause the O-rings to be sucked out from their grooves when the air escapes past
them.
For maintenance of the rotation unit, see the separate documentation.
For maintenance of the down-the-hole rock drill, see the supplier's documentation.
14.3.2 Lubrication
The lubrication points are on the arm, the rotary actuator, the outlet swivel and the air
swivel. For the rotary actuator, lubrication is recommended every two months or every 500
engine hours. Other points must be lubricated daily.
CAUTION
Risk of injury
Special tools are required for service: Article number 9495 6730 00 - 6x screws, 12:9
quality when fitting the adapter.
