SmartROC D65 Tier 4 Final 4 Hardware RCS
45
n When there is no CAN communication or if the I/O module is starting up the LED will
flash five times per second.
n 5V supply for CAN control.
n 24V supply for valves and sensors.
Analogue inputs
n Green LED indicates 5V and 24V supply voltage.
n Red LED indicates short circuit to ground of sensor supply voltage.
The supply voltage must be reset after one second when the short circuit is broken.
Digital inputs and outputs
!
NOTE: The left-hand LED has a signal from pin 2 (B) and the right-hand LED has a
signal from pin 4 (A).
Function/Con-
tact
Black Green Orange* Red
PNP output Load not activated Open circuit
Output not activ-
ated
Output activated
and actuated
Output activated,
but short circuit to
ground
PNP input Input voltage low
No signal on input
Voltage on input
Input active
Does not arise if
the port is initial-
ised as input.
Does not arise if
the port is initial-
ised as input.
NPN output Not activated Output activated
externally
Short circuit to
ground.
The output is ac-
tivated and actu-
ated
Output activated,
but short circuit to
ground
NPN input No signal
Input voltage too
high.
Input activated
(closed to ground)
Does not arise if
the port is initial-
ised as input.
Does not arise if
the port is initial-
ised as input.
PWM output Not activated
Load present
Open circuit
Output not activ-
ated
Output activated
and actuated
Output activated
(low current) or
short circuit to
ground
PWM input Input voltage low
No signal on input
Voltage on input
Input active
Does not arise if
the port is initial-
ised as input.
Does not arise if
the port is initial-
ised as input.
* Orange appears by means of the LED emitting red and green simultaneously.
