SmartROC D65 Tier 4 Final 12 Compressor and air system
173
19 Thermostat
20 Radiator
21 Pressure relief valve (extra equipment)
22 Pressure tank sensor, B456
23 Water separator filter
24 Safety valve
25 Minimum pressure valve
26 Air receiver
27 Restriction
Compressor parts
3 Control valve, high percussion pressure
4 Control valve, low percussion pressure
5 Intake valve
9 Compressor, low pressure stage
10 Compressor, high pressure stage
11 Oil stop valve
13 Pressure Relief Valves
14 Check valve
15 Pressure gauge, tank pressure
16 Pressure gauge, intermediate stage pressure
19 Oil filter
