Atlas Copco SMARTROC D65 TIER 4 FINAL User Manual

SmartROC D65 Tier 4 Final 14 Options
211
11 O-ring
12 Spindle adapter
13 Spindle DHR6RC
14 Circlip
15 Inner tube
16 Outer tube
17 O-ring
18 Hex head screw
19 Deflector 1
20 Deflector 2
Seal 5 on the outlet swivel requires regular lubrication. There is a grease nipple for this on
the adapter housing (8). Grease must be applied daily to this seal (5) via the grease
nipple.
Replace the seals when they start leaking. Leaking cutting seals can cause water and dirt
penetration in the rotation unit. The sealing sleeve around which the seals rotate may also
require replacing if rutted.

Atlas Copco SMARTROC D65 TIER 4 FINAL Specifications

General

Brand	Atlas Copco
Model	SMARTROC D65 TIER 4 FINAL
Category	Industrial Equipment
Language	English
