CHAPTER9 Getting Started with SNMP
Mediant 800 SBC | SNMP Reference Guide
● The concept of trusted managers is a weak form of security and is therefore, not a
required part of SNMPv3 security, which uses authentication and privacy.
● Trusted managers are therefore, not supported in SNMPv3 – thus they apply only
when the device is set to use SNMPv2c.
● If trusted managers are defined, then all community strings work from all trusted
managers. That is, there is no way to associate a community string with particular
trusted managers.
The configuration can be done via ini file, SNMP and Web.
■ ini file: SNMPTRUSTEDMGR_x = <IP address>, where x is the entry index 0 to 4.
■ SNMP: To configure Trusted Managers, the EM must use the SNMP-COMMUNITY-MIB,
snmpCommunityMIB, and snmpTargetMIB.
● To add the first Trusted Manager: This procedure assumes that there is at least one
configured read-write community. There are currently no Trusted Managers. The
TransportTag for columns for all snmpCommunityTable rows are currently empty.
i. Add a row to the snmpTargetAddrTable with these values:
Name=mgr0
TagList=MGR
Params=v2cparams.
ii. Add a row to the snmpTargetAddrExtTable table with these values:
Name=mgr0
snmpTargetAddrTMask=255.255.255.255:0.
The agent does not allow creation of a row in this table unless a corresponding
row exists in the snmpTargetAddrTable.
iii. Set the value of the TransportTag field on each non-TrapGroup row in the
snmpCommunityTable to MGR.
● To add a subsequent Trusted Manager: This procedure assumes that there is at least
one configured read-write community. There are currently one or more Trusted
Managers. The TransportTag for columns for all rows in the snmpCommunityTable are
currently set to MGR. This procedure must be done from one of the existing Trusted
Managers.
i. Add a row to the snmpTargetAddrTable with these values:
Name=mgrN, where N is an unused number between 0 and 4.
TagList=MGR
Params=v2cparams
ii. Add a row to the snmpTargetAddrExtTable table with these values:
Name=mgrN
snmpTargetAddrTMask=255.255.255.255:0.
An alternative to the above procedure is to set the snmpTargetAddrTMask
column while you are creating other rows in the table.
- 179 -

AudioCodes Mediant 800 Specifications

General

Protocols	SIP, H.323
Digital Interfaces	1/2 E1/T1 PRI
Management	Web, CLI, SNMP
Mounting	19-inch rack
Codecs	G.711, G.729, G.722, G.723.1
Power Supply	100-240V AC
Operating Temperature	0 to 40°C
Storage Temperature	-25 to 70°C
Humidity	10% to 90% non-condensing
