SIP User's Manual 134 Document #: LTRT-65412
MP-11x & MP-124
Parameter Description
Web: Dest. IP Address
EMS: Address
[PREFIX_DestAddress]
The destination IP address (in dotted-decimal notation or FQDN) to
where the call is sent. If an FQDN is used (e.g., domain.com), DNS
resolution is performed according to the parameter DNSQueryType.
Notes:
If you define a destination IP Group, then this IP address is not
used for routing and therefore, not required.
To discard outgoing IP calls of a specific Tel-to-IP routing rule,
enter 0.0.0.0. For example, if you want to prohibit dialing of
international calls, then in the 'Dest Phone Prefix' field, enter 00
and in the 'Dest IP Address' field, enter 0.0.0.0.
For routing calls between phones connected to the device (i.e.,
local routing), enter the device's IP address.
When the device's IP address is unknown (e.g., when DHCP is
used), enter IP address 127.0.0.1.
When using domain names, you must enter a DNS server IP
address or alternatively, define these names in the 'Internal DNS
Table' (refer to ''Configuring the Internal DNS Table'' on page
138).
If the string 'ENUM' is specified for the destination IP address, an
ENUM query containing the destination phone number is sent to
the DNS server. The ENUM reply includes a SIP URI used as the
Request-URI in the outgoing INVITE and for routing (if a Proxy is
not used).
The IP address can include wildcards. The 'x' wildcard is used to
represent single digits, e.g., 10.8.8.xx represents all addresses
between 10.8.8.10 to 10.8.8.99. The '*' wildcard represents any
number between 0 and 255, e.g., 10.8.8.* represents all
addresses between 10.8.8.0 and 10.8.8.255.
Web: Port
EMS: Destination Port
[PREFIX_DestPort]
The destination port to where you want to route the call.
Web/EMS: Transport Type
[PREFIX_TransportType]
The transport layer type for sending the IP calls:
[-1] Not Configured
[0] UDP
[1] TCP
[2] TLS
Note: When set to Not Configured (-1),, the transport type defined by
the parameter SIPTransportType (refer to ''SIP General Parameters''
on page 92) i
s used.
Web: Dest IP Group ID
EMS: Destination IP Group
ID
[PREFIX_DestIPGroupID]
The IP Group (1-9) to where you want to route the call. The SIP
INVITE messages are sent to the IP address defined for the Proxy
Set ID (refer to ''Configuring the Proxy Sets Table'' on page 95) tha
t
is associated with this IP Group.
Notes:
If you choose an IP Group, it is unnecessary to configure a
destination IP address. However, if both parameters are
configured, the INVITE message is sent only to this IP Group.
If the parameter AlwaysUseRouteTable is set to 1 (in the 'IP
Group' table, refer to ''Configuring the IP Groups'' on page 99),
