Version 5.8 135 September 2009
SIP User's Manual 3. Web-Based Management
Parameter Description
then the request URI host name in the INVITE message is set to
the value of the parameter PREFIX_DestAddress (if not empty);
otherwise, it is set to the value of the parameter 'SIP Group
Name' (defined in the 'IP Group' table).
IP Profile ID
[PREFIX_ProfileId]
The IP Profile ID (defined by the parameter IPProfile) assigned to
this IP destination call. This allows you to assign numerous
configuration attributes per routing rule.
Web/EMS: Charge Code
[PREFIX_MeteringCode]
An optional Charge Code (1 to 25) that is applied to each routing rule
to associate it with an entry in the Charge Code table (refer to
“Configuring the Charge Codes Table” on page 116).
Status
A read-only field displaying the Quality of Service of the destination
IP address:
n/a = Alternative Routing feature is disabled.
OK = IP route is available.
Ping Error = No ping to IP destination; route is not available.
QoS Low = Bad QoS of IP destination; route is not available.
DNS Error = No DNS resolution (only when domain name is used
instead of an IP address).
3.3.4.8.3 Configuring the IP to Trunk Group Routing Table
The 'IP to Hunt Group Routing Table' page provides a table for routing incoming IP calls to
groups of channels (FXS/FXO endpoints)called Hunt Groups. Hunt Group ID's are assigned
to the device's channels in the 'Endpoint Phone Number' page (refer to Configuring the
Endpoint Phone Numbers on page 149). You can a
dd up to 24 IP-to-Hunt Group routing
rules in the table.
Note: If the IP2IP application is enabled the 'Inbound IP Routing Table' page
appears instead (refer to Configuring the Inbound IP Routing Table).
The IP-to-Tel calls are routed to Hunt Groups according to any one of the following (or a
combination thereof) criteria:
Destination and source host prefix
Destination and source phone prefix
Source IP address
Once the call is routed to the specific Hunt Group, the call is sent to the device's channels
pertaining to that Hunt Group. The specific channel within the Hunt Group to which the call
is sent is determined according to the Hunt Group's channel selection mode. This channel
selection mode can be defined per Hunt Group (refer to ‘‘Configuring the Hunt Group
Settings’’ on page 150) o
r for all Hunt Groups using the global parameter
ChannelSelectMode.(refer to ''SIP General Parameters'' on page 92).
