AudioCodes MP-124 User Manual

SIP User's Manual 324 Document #: LTRT-65412
MP-11x & MP-124
Parameter Description
No Answer
[KeyCFNoAnswer]
Keypad sequence that activates the forward on no answer
option.
On Busy
[KeyCFBusy]
Keypad sequence that activates the forward on busy option.
On Busy or No Answer
[KeyCFBusyOrNoAnswer]
Keypad sequence that activates the forward on 'busy or no
answer' option.
Do Not Disturb
[KeyCFDoNotDisturb]
Keypad sequence that activates the Do Not Disturb option
(immediately reject incoming calls).
To activate the required forward method from the telephone:
1. Dial the preconfigured sequence number on the keypad; a dial tone is heard.
2. Dial the telephone number to which the call is forwarded (terminate the number with #); a
confirmation tone is heard.
Deactivate
[KeyCFDeact]
Keypad sequence that deactivates any of the call forward
options. After the sequence is pressed, a confirmation tone is
heard.
Keypad Feature - Caller ID Restriction Parameters
Activate
[KeyCLIR]
Keypad sequence that activates the restricted Caller ID option.
After the sequence is pressed, a confirmation tone is heard.
Deactivate
[KeyCLIRDeact]
Keypad sequence that deactivates the restricted Caller ID
option. After the sequence is pressed, a confirmation tone is
heard.
Keypad Feature - Hotline Parameters
Activate
[KeyHotLine]
Keypad sequence that activates the delayed hotline option.
To activate the delayed hotline option from the telephone,
perform the following:
 Dial the preconfigured sequence number on the keypad; a
dial tone is heard.
 Dial the telephone number to which the phone automatically
dials after a configurable delay (terminate the number with
#); a confirmation tone is heard.
Deactivate
[KeyHotLineDeact]
Keypad sequence that deactivates the delayed hotline option.
After the sequence is pressed, a confirmation tone is heard.
Keypad Feature - Transfer Parameters
Blind
[KeyBlindTransfer]
Keypad sequence that activates blind transfer for Tel-to-IP
calls. There are two possible scenarios:
 Option 1: After this sequence is dialed, the current call is put
on hold (using Re-INVITE), a dial tone is played to the
phone, and then phone number collection starts.
 Option 2: A Hook-Flash is pressed, the current call is put on
hold, a dial tone is played to the phone, and then digit
collection starts. After this sequence is identified, the device
continues the collection of the destination phone number.
For both options, after the phone number is collected, it's sent
to the transferee in a SIP REFER request (without a Replaces
header). The call is then terminated and a confirmation tone is
played to the phone. If the phone number collection fails due to
a mismatch, a reorder tone is played to the phone.

AudioCodes MP-124 Specifications

General

Model	MP-124
Category	Gateway
Analog Ports	24 FXS
Ethernet Ports	2
Protocol Support	SIP, H.323
Fax Support	T.38, G.711 pass-through
Power Supply	100-240VAC, 50-60Hz
Operating Temperature	0°C to 40°C
Voice Codecs	G.711, G.729, G.723.1, G.726
Management	SNMP
Storage Temperature	-20°C to 70°C
Humidity	10% to 90%, non-condensing
Network Interface	10/100Base-T Ethernet
