AutomationDirect DL205 User Manual

DL205 User Manual, 4th Edition, Rev. D
xvii
Table of Contents
Forcing I/O Points 9–26
Regular Forcing with Direct Access 9–28
Bit Override Forcing 9–29
Bit Override Indicators 9–29
Reset the PLC to Factory Defaults 9-30
Appendix A: Auxiliary Functions A–1
Introduction A–2
What are Auxiliary Functions? A–2
Accessing AUX Functions via DirectSOFT A–3
Accessing AUX Functions via the Handheld Programmer A–3
AUX 2* — RLL Operations A–4
AUX 21-24 A–4
AUX 21 Check Program A–4
AUX 22 Change Reference A–4
AUX 23 Clear Ladder Range A–4
AUX 24 Clear Ladders A–4
AUX 3* — V-memory Operations A–5
AUX 31 A–5
AUX 31 Clear V-Memory A–5
AUX 4* — I/O Configuration A–5
AUX 41-46 A–5
AUX 41 Show I/O Configuration A–5
AUX 42 I/O Diagnostics A–5
AUX 44 Power-up Configuration Check A–5
AUX 45 Select Configuration A–6
AUX 46 to I/O Configuration A–6
AUX 5* — CPU Configuration A–7
AUX 51-5C A–7
AUX 51 Modify Program Name A–7
AUX 52 Display/Change Calendar A–7
AUX 53 Display Scan Time A–8
AUX 54 Initialize Scratchpad A–8
AUX 55 Set Watchdog Timer A–8
AUX 56 CPU Network Address A–8
AUX 57 Set Retentive Ranges A–9

AutomationDirect DL205 Specifications

General

Brand	AutomationDirect
Model	DL205
Category	Controller
Language	English
