DirectLOGIC™ Part Numbering System
As you examine this manual, you will notice there are many different products available.
Sometimes it is difficult to remember the specifications for any given product. However, if
you take a few minutes to understand the numbering system, it may save you some time and
confusion. The charts below show how the part numbering systems work for each product
category. Part numbers for accessory items such as cables, batteries, memory cartridges, etc, are
typically an abbreviation of the description for the item.
CPUs
Specialty CPUs
DL05/06 Product family
DL105 Product family
DL205 Product family
DL305 Product family
DL405 Product family
D0/F0
D1/F1
D2/F2
D3/F3
D4/F4
Class of CPU / Abbreviation 230...,330...,430...
Denotes a differentiation between
similar modules
–1, –2, –3, –4
Bases
D2/F2
D3/F3
D4/F4
Number of slots ##B
Type of Base DC or empty
Discrete I/O
Number of points 04/08/12/16/32/64
Input N
p
Output T
p
Combination C
AC A
DC D
Either E
Relay R
Current Sinking 1
g
Current Sourcing 2
g
Current Sinking/Sourcing 3
High Current H
g
Isolation S
Fast I/O F
Denotes a differentiation between
similar modules
–1, –2, –3, –4
D3– 16 ND2–1
D4– 16 ND2F
D3– 05B DC
D4– 440DC –1
DL205 Product family
DL305 Product family
DL405 Product family
DL05/06 Product family
DL205 Product family
DL305 Product family
DL405 Product family
D0/F0
D2/F2
D3/F3
D4/F4
