AutomationDirect DL205 User Manual

DL205 User Manual, 4th Edition, Rev. D
1-6
Chapter 1: Getting Started
1
2
3
4
5
6
7
8
9
10
11
12
13
14
A
B
C
D
1–6
PROGRAMMING
Handheld Programmer
with Built-in RLL
PLUS
Direct SOFT Programming
for Windows
AC INPUT
8pt 110 VAC
16pt 110 VAC
Direct
LOGIC DL205 Family
DC INPUT
8pt 12–24 VDC
16pt 24 VDC
32pt 24 VDC
32pt 5–15 VDC
SPECIALTY MODULES
High Speed Counters
CPU Slot Controllers
Remote Masters
Remote Slaves
Communications
Temperature Input
Filler Module
AC OUTPUT
8pt 18–220 VAC
12pt 18–110 VAC
2 commons
RELAY OUTPUT
4pt 5–30 VDC
5–240VAC
8pt 5–30 VDC
5 –240 VAC
12pt 5–30VDC
5–240VAC
(isolated pts.module
available)
ANALOG
CPUs
DL230 – 2.0K Built-in EEPROM Memory
DL240 – 2.5K Built-in EEPROM Memory
DL250–1 – 7.6K Built-in Flash Memory
DL260 – 15.8K Built-in Flash Memory
BASES
3 Slot Base, 110/220VAC, 24VDC
4 Slot Base, 110/220VAC, 24VDC
6 Slot Base, 110/220VAC, 24VDC, 125 VDC
9 Slot Base, 110/220VAC, 24VDC, 125 VDC
DC OUTPUT
4pt 12–24 VDC
8pt 12–24 VDC
16pt 12–24 VDC
2 Commons
32pt 12–24 VDC
4 Commons
4CH INPUT
8CH INPUT
2CH OUTPUT
8CH OUTPUT
4 IN/2 OUT
8 IN/4 OUT
ANALOG
