Explanationofoperatingcontrols
(Power on switch/energy selector switch
(MODE)
Temperatureselection
PowerOnswitchframeheating
IndicatorLEDfailure
IndicatorLEDframeheating
IndicatorLED/operatingmodedisplay
Temperatureleveldisplay.
NOTAPPLICABLE
Externaldisplay“failure”(red)
Externaldisplay“inoperation”(blue)
Explanations
The refrigerator is equipped to operate on
mainspower,12vDCorliquidgas.Selectthe
desired power supply by turning the energy
selectorswitch(1).
The energy selector switch (1) has four
settings:Off,mainsvoltage(230vAC),direct-
current voltage (battery, 12v DC), gas (liquid
gaspropane/butane)
SwitchtherefrigeratorONorOFFbypressing
button(1)for3seconds.Button(1)allowsyou
toeitherinitiatetherequestedenergysupply
oractivatedimmingoftheLEDbrightness.By
pushingonce,theindicatorsilluminatefor10
seconds.
Button (3) allows you to switch on the
frame heating in order to avoid a rising of
condensation water due to high humidity.
During the frame heating operation the
indicatorLED(5)isilluminating.
Electrical Operation
MESAppliances(manualenergyselection)
To start the refrigerator, press button (1) for
3seconds.
The LED (6) of the previously selected
operatingmodeilluminates:
230voperation
12voperation
Gasoperation
Change the operating mode by pressing
button (1) again.  The appropriate indicator
LEDwillilluminate.
Press button (1) several times until the
indicatorLED(6)illuminates.
Theignitionprocessisactivatedautomatically
bymeansofanautomaticigniter.
i
Theignitionsystemwillmake2
ignitionattemptswith25seconds
intervalwhentheburnerfailstolight.
Ifrepeatedattemptsfailtostartthe
operation,afaultisindicated(please
refertofailureindicationfoundon
page109).
Setting of The Cooling Compartment
Temperature
Select the desired cooling compartment
temperaturebypressingbutton(2).
The LED display (7) of the selected
temperaturesettingisilluminated.
The scale starts with MIN position at the
bottom LED position (smallcrystal = highest
temperature) and climbs up to MAX position
at the upper LED position (largest crystal =
lowesttemperature).  Note:Thetemperature
levels do not relate to absolute temperature
values.
