CARAVANANDTOWVEHICLE
Holesshouldnotbedrilledineither
thecouplingheador‘“A”Frame
memberswithoutpriorconsultation
withthechassismanufacturer.
Ifyoudondyourouttsnaking,trytokeep
the steering wheel in a central position as
far as possible, slow down gently and avoid
brakingifpossible.
Road Lighting
All caravans are tted with a single 13 pin
lead.  Where the connector for the car does
notmatchthatofthe caravan an adaptoror
replacementcablewillberequired.Pleaseask
yoursupplyingretailerformoreinformation.
13 PIN CARAVAN LEAD
ITEM
MODEL
CIRRUS TEST NUMBERISSUE NUMBERDATEDRAWN BY
PART NUMBER
CARAVAN 13 PIN PLUG
DH 10-08-2012
1
8
1
4
2
3
12
11
10
9
7
6
5
13
VIEWED FROM
THE REAR
13 PIN PLUG
KEY:
1Left-handdirection,indicatorlight
2.Rightfoglight
3.CommonreturnforCoreNos.1,2and4to8.
4.Right-handdirectionindicatorlight
5.Right-handrearpositionandmarkerlights,
andrearregistration,plateilluminationdevice.
6.Stoplights
7. Left-hand rear position and marker lights
andrearregistration,plateilluminationdevice
8.Reversinglight
9.Continuouspowersupply
10.Powersupplycontrolledbyignitionswitch
11.Returnforcoreno10
12.Codingforcoupledtrailer
13.Returnforcoreno9
8. ROAD LIGHTS
Itisimportantthatalltheroadlightsonyour
Baileycaravanarecheckedbeforeyousetout
onajourney.
All lights must be working in the correct
mannerforthevehicletoberoadlegal.
Clean the outside of the lights with a non-
abrasiveornon-aggressivecleaningsolution.
Always replace a lamp which is showing any
signofdamage.
