HEATINGSYSTEMS
pumpswitch).
Openhotwatertapsinkitchenandbathroom,
(set preselecting mixing taps or single-lever
ttingsto“hot”).Leavethettingsopenfor
as long as it takes for the boiler to displace
theairandllupandthewatertoowwithout
interruption.
!
     If justthecoldwatersystem is being
operated without using the water
heater, the heater tank also lls up
withwater.Toavoidfrostdamagethe
boiler must be drained through the
drainvalveevenifitwasnotoperated.
!
Whenconnectingtoacentralwater
supply(ruralorcitymains)apressure
reductionvalvemustalwaysbe
installedtopreventabove2.8bar
fromdevelopinginthewaterheater.
Draining the Water Heater
Switchoffpowertowaterpump(mainorpump
switch).
Openhotwatertapsinkitchenandbathroom.
Inordertocheckthewaterthatisowingout,
place an appropriate container (capacity 10
litres)beneaththedrainvalve(FrostControl)
drainagemuff.
Turn the rotary switch on the drain valveby
180°C until it engages, whereby the push
buttonmovesoutandthedrainvalveopens.
!
Checkwhetherallofthewaterinthe
boiler(10litres)hasbeendrainedinto
thecontainerviathedrainvalve.
There shall be no claims under
guaranteefordamagecausedbyfrost.
Methods of Operation
Heating is possible without restrictions with
gas, electrical and mixed operation, with or
withoutwater.
!
Checktomakesurethecowlis
unobstructed.Besuretoremoveany
coversthatmaybepresent.
Turn on gas cylinder and open quick-acting
valveinthegassupplyline.
Check whether the power supply fuse
protection on the camp site is adequate for
the 900W (3.9A) or 1800W (7.8A) that have
beenselectedusingthepowerselectorswitch.
Summer Operation (boiler operation only)
Select gas or electrical operation using the
power selector switch.  Illumination of the
yellow LED on the power selector switch
indicatesthattheunitisoperatingon230v.
Mixed operation (gas and electrical) is not
possible in summer mode.  With this setting
the unit automatically selects electrical
operationwithapreselectedpowersettingof
900Wor1800W.
Move the rotary switch on the control panel
to40°Cor60°C.ThegreenandyellowLEDs
lightup.
When the selected water temperature is
reached(40°Cor60°C)theheatershutsoff
andtheyyellowLEDgoesoff.
Winter Operation
Heating with water temperature monitoring.
Selectgas,electricalormixedoperationusing
the power switch.  Illumination ofthe yellow
LED on the power selector switch indicates
thattheunitisoperatingwith230v.
Move rotary switch on control panel to
operatingposition.
Settherotaryswitchtothedesiredthermostat
setting(1–5).ThegreenLEDforoperationis
lit and simultaneously indicates the position
oftheselectedroomtemperature.Theyellow
LEDindicatesthewater’sheat-upphase.
The device automatically selects the
required power setting in accordance with
the temperature difference between the
temperature selected on the control panel
andthecurrentroomtemperature.Whenthe
room temperature selected on the control
panelisreached,theheaterswitchesbackto
the smallest setting and heats the water to
60°C.Oncethewatertemperatureisreached
the heater switches off and the yellow LED
goesout.
