Hitching the caravan to the tow vehicle
1. Ensure that the caravan is in a suitable
position, and secure with the handbrake
fullyon.
2. Fullyraiseallfourcornersteadies.
3. Shutandlockthecaravanexterior.
4. Gaugetheheightofthecar’stowballthen
raiseorlowertheheightofthecaravan’s
towing hitch to ensure that it is high
enoughtopassoveritcleanlyandnothit
thetowball.Rotatingthecaravan’sjockey
wheel handle can do this:  Clockwise to
lower,anti-clockwisetoraise.
5. Theassistantshould positionthemselves
by the front near side of the caravan so
thattheycanextendanarmhorizontally
to indicate the position of the caravan’s
towinghitch.
6. Removethecar’stowballcoverandkeep
itinasecureplaceinthecar.
7.  Slowlyreversethetowingvehicletowards
the caravan When reversing the towing
vehicletowardsthecaravanalwaysensure
that any pedestrians and your assistant
arevisibleatalltimes.
8. Whenreversingaimthetowballofthecar
directlyatthecaravantowinghitch.
9. When the car’s towball is as near to the
caravan’s towing hitch as possible fully
apply the car’s handbrake, turn off the
engineandleavethecarinrstgear(Park
or‘P’positionforautomatics).
10. Thenalpositioningshouldbecarriedout
bymanoeuvringbyhand.
11. Carefullyreleasethecaravan’shandbrake.
12. Manoeuvrethecaravan’stowhitchdirectly
overthetowingvehicle’stowball.Always
manoeuvrethevehiclebypushing/pulling
on the grab handles.  When the caravan
is in the correct position fully apply the
handbrake.
13. Raisethehandleonthecaravantowhitch
untilitclicksandremainsatanangle.
14. Rotatethejockeywheelhandleclockwise
tolowerthehitchontothetowball.When
thetowhitchclicksandthehandledropsto
thehorizontalpositionitisengaged.The
hitchheadisttedwithavisualindicator
onthefrontradiustoshowwhetherornot
itisproperlyconnectedtothetowball.A
green band will show immediately below
theredindicatorbuttononthehitchhead
whenaproperconnectionhasbeenmade.
15. Connect secondary braking cable as per
theinstructionsintheprevioussection.
16. Testthatthehitchisnowfullyengagedby
slightlyraisingthecaravanhitchfromthe
car towball by winding the jockey wheel
handle anti-clockwise.  The hitch should
not release from the car towball.  Only
raisetherearofthecarenoughtocheck
thehitchisfullyengaged.
17. Turn the jockey wheel winding handle to
lowerthecaravan.Whenthewheelisfully
retracted,releasetheclampandraisethe
jockeywheeltotravelposition.
18. Oncethejockeywheelisintravelposition
and the wheel is located in the recess,
tightentheclampagain.
19. All caravans are tted with a single 13
pin lead.  Where the connector for the
car does not match that of the caravan
an adaptor or replacement cable will
be required.  Please ask your supplying
retailerfordetails.
Connect the lead to the receiving socket on
the towing vehicle ensuring there is enough
loosecableforcornering,butnottoomuchso
thatitcandragontheground.
20.Checkalltowingvehicleandcaravanroad
lights are working, and the operation of
thebrakelights.
21. Pick up any levelling pads or levelling
boards.
22.Fullyreleasethecaravanhandbrake.
23.Carryoutasecondcheckthatthehitchis
secureandthesecondarybrakingcableis
connected.
24.Adjustthe car’s driving mirrors fromthe
driving seat to ensure good rearward
visibility.
