THEWATERSYSTEM
14b. UNICORN III TWIN AXLE
WATER SYSTEM
Water Supply
Thismodelissuppliedwith an on-board40L
tankandinbuiltsubmersiblepumpaswellas
anexternal12v submersiblepump controlled
byapressureswitch.Theexternalpumpcan
beusedtosupplywaterdirectlytothecaravan
fromanoutsidewatersupplyoritcanbeused
tolltheon-boardtank.
External supply
The water inlet is located in the off-side
exterior wall,protected by a lift up lid.  This
pump is designed to simplify the connection
of an outside water supply to the caravan
system.
The Whale Watermaster comprises a
wall socket, plug complete with hose and
submersible pump.  The plug and socket
combine both the water and electric
connections.  Designed for pumping fresh
waterintothecaravan,theWhaleWatermaster
isalsocapableofsupplyingwatertoawater
heater.
Operation
•Openonecoldtap(e.g.atthekitchensink)
•Placethepumpintoawatercontainer
•Insert the plug into the wall socket and
closethelidtolockthepluginplace
•Adjust the dust cover over the opening
in the container (please note: the dust
covershould not besecured to the water
container as airmustbe allowed to enter
the container to replace the water being
pumpedout)
•Switch on the 12v supply at the main
controlpanel(pumpisolatorswitch)
•Waterwillowfromtheopentapexpelling
anytrappedairinafewseconds
•Turn offthetap;the systemis now ready
foruse
i
Thepumphosecanbeinsertedinto
thegrooveontheplugtokeepthe
pumpoffthegroundwhilere-lling
thewatercontainer.
